1. PFF5-201GBLK – Front Wishbone Rear Bush, Caster Adjusted
PFF5-201G offers additional +2° of caster and is a high performance option to PFF5-201. Aimed at offering greater precision with improved geometry for people wanting the very best from their Mini. This new part, fitted to the rear of the front wishbone has a hard anodised aluminium outer shell with one of our unique low friction polyurethane centre bushes. The poly/alu combination creates a low friction rotating bush reducing the forces acting on the arm. Lower arm deflection has been decreased by reducing the compliant material within the aluminium shell. Additional caster angle will give more negative camber when cornering giving improved tyre to road contact. Results are improved geometry when turning giving additional grip, steering control and feel with less movement in the arm under cornering and braking.
OEM Part Number: 31126767530
1. PFF5K-201BLK – Front Wishbone Rear Bush & Bracket
PFF5K-201 Front Wishbone Rear Bush & Bracket fits Mini Gen 2 R56/R57 and uses our existing PFF5-101 bush. A lasting, better-performing polyurethane bush alternative, like Powerflex, has always been a popular upgrade for owners but whilst our bushes are very easy to fit, sometimes removing the original bushes from the OE housing brackets can be difficult, especially for those with limited access to pressing or pulling tools. Pre-installed in quality brackets, they simply require fitting onto the arm and bolting into position saving both time and money.
OEM Part Number: 31126767530
1. PFF5-201BLK – Front Wishbone Rear Bush
OEM Part Number: 31126767530
2. PFF5-102-24BLK – Front Anti Roll Bar Bush 24mm
Please check anti roll bar diameter before ordering
OEM Part Number: 31356758302
2. PFF5-102-235BLK – Front Anti Roll Bar Bush 23.5mm
Please check anti roll bar diameter before ordering
OEM Part Number: 31356772844
2. PFF5-102-225BLK – Front Anti Roll Bar Bush 22.5mm
Please check anti roll bar diameter before ordering
OEM Part Number: 3135675714
2. PFF5-102-215BLK – Front Anti Roll Bar Bush 21.5mm
Please check anti roll bar diameter before ordering
OEM Part Number: 31356772843
6. PFF5-206BLK – Lower Engine Mount Small Bush
OEM Part Number: 22116783094
7. PFF5-207BLK – Lower Engine Mount Large Bush Insert
OEM Part Number: 22116783094
9. PFR5-109BLK – Rear Control Arm Bush
OEM Part Number: 33326768726
OEM Part Number: 33326768724
10. PFR5-1103BLK – Rear Trailing Arm Front Bush 60mm
PFR5-1103 is a complete bush that fits into trailing arm bracket OE numbers: 33306799089 33306799090, 33309807099 and 3330980710. For inserts use PFR5-1102 which fit into the original rubber bush.
OEM Part Number: 33306799089
OEM Part Number: 33306799090
OEM Part Number: 33309807099
10. PFR5-1102BLK – Rear Trailing Arm Front Bush Insert
PFR5-1102 are inserts which fit into the original rubber bush. For a complete bush use PFR5-1103
11. PFR5-111-17BLK – Rear Anti Roll Bar Bush 17mm
This part fits vehicles with a 17mm diameter anti roll bar.
OEM Part Number: 33556756151
11. PFR5-111-16BLK – Rear Anti Roll Bar Bush 16mm
This part fits vehicles with a 16mm anti roll bar diameter.
OEM Part Number: 33556754823
15. PFR5-115BLK – Rear Shock Top Mounting Bush
OEM Part Number: 33526754123
OEM Part Number: 33526754124
20. PFF5-220BLK – Lower Torque Mount, Track Use
Designed to replace the softer rubber voided OE mount that is prone to cracking, allowing for excessive engine movement and wheel hop, PFF5-220BLK Lower Torque Mount Bracket & Bush (Black 95A) is a huge 500% stiffer than OE and available in our Black Series for hard Track and Motorsport use. Combining a CNC machined aluminium lower torque mount with various durometer bush options to suit differing states of tune, it’s a great way of reducing engine movement for more balanced on/off throttle handling while improving gear shifting precision. It’s also super easy to replace – just two bolts and it’s out with the old, in with the new and no pressing out of any rubber! A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 22116783094
OEM Part Number: 22114052474
OEM Part Number: 22116772040
24. PFF5-224BLK – Upper Engine Mount Insert (Track)
PFF5-224BLK is made from our stiffest 95A Black Series material, providing a no-compromise performance option for track-focused builds. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 22114050886 / 22 11 4 050 886
OEM Part Number: 22116782374 / 22 11 6 782 374
OEM Part Number: 4050886 / 6782374
30. PFF5-225BLK – Upper Gearbox Mount Insert (Track)
PFF5-225 Upper Gearbox Mount Insert fills the voiding in the OEM gearbox mount, reducing engine and transmission movement for sharper gear changes and more precise and settled transmission response during acceleration and deceleration.
OEM Part Number: 22316784355
OEM Part Number: 22316784357
