2. PFF3-202 – Front Tie Bar Rear Bush
OEM Part Number: 4F0407183 / 4F0407183E
OEM Part Number: 4D0407183AB / 4D0407183AC
3. PFF3-203G – Front Upper Control Arm Bush – Camber Adj
PFF3-203G allows you to fine-tune the front camber/caster/toe. Perfect for dialling in the alignment, improving the handling and minimizing tyre wear. The offset sleeve allows up to +/- 0.3° of camber adjustment.
OEM Part Number: 4B0407515 / 4D0407515C / 4E0407515D / 4H0407515B
OEM Part Number: 4E0407509 / 4E0 407 509 / 4E0407510 / 4E0 407 510
OEM Part Number: 8K0407515 / 8D0407515C
3. PFF3-203 – Front Upper Control Arm Bush
OEM Part Number: 4B0407515 / 4D0407515C / 4E0407515D / 4H0407515B
OEM Part Number: 4E0407509 / 4E0 407 509 / 4E0407510 / 4E0 407 510
OEM Part Number: 8K0407515 / 8D0407515C
4. PFF3-204-27 – Front Anti Roll Bar Bush 27mm
Please check anti roll bar diameter before ordering.
4. PFF3-204-25 – Front Anti Roll Bar Bush 25mm
Please check anti roll bar diameter before ordering.
OEM Part Number: Bush = 8K0411327A / 8K0 411 327 A
OEM Part Number: Bar = 8K0411309M / 8K0 411 309 M
4. PFF3-204-24 – Front Anti Roll Bar Bush 24mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 8K0 411 327 A
4. PFF3-204-23 – Front Anti Roll Bar Bush 23mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 8K0 411 327 A
5. PFF3-213 – Front Anti Roll Bar Link Bush
Fits bracket with bolts at each end, does not fit bracket with ball joint at each end.
OEM Part Number: 8D0411317D
OEM Part Number: 8K0411317E
OEM Part Number: 8K0411317D
10. PFR3-210-15 – Rear Anti Roll Bar Bush 15mm
OEM Part Number: 8A0511439 Clamp
11. PFF3-211 – Front Lower Arm Inner Bush
On some subframes where the arm fits into the subframe an extra lug is sometimes present and may require grinding away.
OEM Part Number: 4D0407182G
12. PFR3-1112 – Rear Lower Arm Rear Bush
OEM Part Number: 4B0 511 523
14. PFR3-1114 – Rear Upper Arm Bush
OEM Part Number: 4B0 505 185
15. PFR3-1115 – Rear Hub To Arm Bush
OEM Part Number: 8E0 505 172 A
16. PFF3-221 – Engine Snub Nose Mount
This part fits vehicles with a D shape engine mount spigot. For vehicles that use a cylindrical spigot, please use PFF3-220.
OEM Part Number: 8E0199339
16. PFF3-220 – Engine Snub Nose Mount
This part fits vehicles with a cylindrical engine mount spigot. For vehicles that use a D shape spigot, please use PFF3-221.
OEM Part Number: 8D0199339A
OEM Part Number: 8D0199339D
OEM Part Number: 8D0199339F
17. PFR3-1117 – Rear Tie Rod Inner Bush
OEM Part Number: 4Z7 501 530 (ARM)
18. PFR3-1118 – Rear Tie Rod Outer Bush
Does not fit 8-cylinder A6 Quattro/S6 models. Fits cast aluminium arms only.
OEM Part Number: Arm = 4Z7501530
20. PFR3-1120 – Rear Subframe Mounting Bush
OEM Part Number: 8E0505145
21. PFR3-1111 – Rear Lower Arm Front Bush
OEM Part Number: 4B0505311
OEM Part Number: 4B0505312
22. PFR3-1116 – Rear Anti Roll Bar Link Bush
OEM Part Number: 1J0411327A
31. PFR3-1131 – Rear Diff Front Mounting Bush
PFR3-1131 includes a CNC machined aluminium outer shell to house the polyurethane bush for maximum control of the rear diff.
OEM Part Number: 4B3 599 381
32. PFR3-1132 – Rear Diff Rear Mounting Bush
OEM Part Number: 4B3 599 257 A
