Powerflex-puslat 3 Series
Powerflex-puslat ovat markkinoiden suosituin uretaanipuslamerkki. Powerflexin polyuretaanipuslat antavat alustalle jämäkkyyttä, joka tuntuu ajotuntumassa ja renkaiden vähäisemmässä kulumisessakin, kun pyöränkulmat eivät pääse muuttumaan kovassa rasituksessa väljien puslien takia. Tavalliseen katuajoon suosittelemme road-sarjan puslia. Black-sarjan puslat ovat jo melko jäykkiä, joten ne sopivat kilpakäyttöön radalle tai muuhun vastaavaan vaativaan käyttöön
LISÄTIEDOT
1. PFF5-4601
This bush is designed to fit the 66mm aluminium bush mounting bracket. Please ensure you have the correct size bush before fitting.
1. PFF5-4601-60
PFF5-4601-60 is for the earlier models with 60 bore mounting – check diameter before ordering
1. PFF5-5601
PFF5-5601 is a high performance option to PFF5-4601, and aimed at offering greater precision for people wanting the very best from their E46 or Z4. This new part, fitted to the rear of the front wishbone has a hard anodised aluminium outer shell with one of our unique low friction polyurethane centre bushes. The poly/alu combination creates a low friction rotating bush reducing the forces acting on the arm. Lower arm deflection has been decreased by reducing the compliant material within the aluminium shell. Results are less movement in the arm under cornering and braking, improving steering control and feel. This bush is designed to fit the 66mm aluminium bush. Please ensure you have the correct size bush before fitting.
1. PFF5-5601-60
PFF5-5601-60 is a high performance option to PFF5-4601-60, and aimed at offering greater precision for people wanting the very best from their E46 or Z4. This new part, fitted to the rear of the front wishbone has a hard anodised aluminium outer shell with one of our unique low friction polyurethane centre bushes. The poly/alu combination creates a low friction rotating bush reducing the forces acting on the arm. Lower arm deflection has been decreased by reducing the compliant material within the aluminium shell. Results are less movement in the arm under cornering and braking, improving steering control and feel. PFF5-5601-60 is for the earlier models with 60mm bore mounting bracket. Please ensure you have the correct size bush before fitting.
1. PFF5-5601G
PFF5-5601G offers additional +0.5 of caster over PFF5-5601 and is a high performance option to PFF5-4601, and aimed at offering greater precision with improved geometry for people wanting the very best from their E46 or Z4. This new part, fitted to the rear of the front wishbone has a hard anodised aluminium outer shell with one of our unique low friction polyurethane centre bushes. The poly/alu combination creates a low friction rotating bush reducing the forces acting on the arm. Lower arm deflection has been decreased by reducing the compliant material within the aluminium shell. Results are less movement in the arm under cornering and braking, improving steering control and feel. This bush is designed to fit the 66mm aluminium bush. Please ensure you have the correct size bush before fitting. Testing during the development of this bush has indicated stiffness gains of 128% compared with the original rubber bush. Our Black Series part increases siffness by 28%, to give an 190% increase in stiffness over the original part
1. PFF5-5601G-60
PFF5-5601G-60 offers additional +0.33 of caster over PFF5-5601-60 and is a high performance option to PFF5-4601-60, and aimed at offering greater precision for people wanting the very best from their E46 or Z4. This new part, fitted to the rear of the front wishbone has a hard anodised aluminium outer shell with one of our unique low friction polyurethane centre bushes. The poly/alu combination creates a low friction rotating bush reducing the forces acting on the arm. Lower arm deflection has been decreased by reducing the compliant material within the aluminium shell. Results are less movement in the arm under cornering and braking, improving steering control and feel. PFF5-5601-60 is for the earlier models with 60mm bore mounting bracket. Please ensure you have the correct size bush before fitting. Testing during the development of this bush has indicated stiffness gains of 128% compared with the original rubber bush. Our Black Series part increases siffness by 28%, to give an 190% increase in stiffness over the original part
2. PFF5-4602-21
Please check Anti roll bar size before ordering
2. PFF5-4602-23
Please check Anti roll bar size before ordering
2. PFF5-4602-23.5
Please check Anti roll bar size before ordering
2. PFF5-4602-24
Please check Anti roll bar size before ordering
2. PFF5-4602-26
Please check Anti roll bar size before ordering
2. PFF5-4602-27
Please check Anti roll bar size before ordering
2. PFF5-4602-30.8
Fits CSL models Please check Anti roll bar size before ordering
4. PFR5-504-15
Please check anti roll bar diameter before ordering – Some part numbers may be described as for the rear but are also for the front anti roll bar on some models. It will not fit E24 6 series models built before 05/1982.
4. PFR5-504-18
Please check anti roll bar diameter before ordering – Some part numbers may be described as for the rear but are also for the front anti roll bar on some models. It will not fit E24 6 series models built before 05/1982.
4. PFR5-504-19
Please check anti roll bar diameter before ordering – Some part numbers may be described as for the rear but are also for the front anti roll bar on some models. It will not fit E24 6 series models built before 05/1982.
4. PFR5-504-215
Please check anti roll bar diameter before ordering – Some part numbers may be described as for the rear but are also for the front anti roll bar on some models.
4. PFR5-504-22.5
Please check anti roll bar diameter before ordering – Some part numbers may be described as for the rear but are also for the front anti roll bar on some models
10. PFR5-4614
Fits all X3, E46 vehicles except M3 and all Z4 except Z4M. Fits into voids in bush.
11. PFR5-4613
Fits all X3, E46 and Z4 vehicles including M3 and Z4M. Fits into voids in original bush.
19. PFR5-4615G
PFR5-4615G Adjustable Rear Control Arm provides on car rear camber adjustment, allowing a +1.0 to -3.0 change for precision alignment – Useful to correct excessive camber on heavily lowered cars. This arm includes high performance polyurethane bushes that are suitable for road and track use without the comfort and longevity issues associated with spherical joints. PFR5-4615G replaces the original arm and bush OE numbers: 33326770813 and 33326770824 respectively. For a replacement bush only to fit in the original arm, please use PFR5-4616.
19. PFR5-4616
This part replaces the bush in the original arm OE number: 33326770813 and 33326770824 respectively. To make adjustments to the vehicles camber angles for precision alignment, please use PFR5-4615G that replaces the original arm and bush.
30. PFR5-5630-10
Suits cars with a standard and aftermarket rear shock absorber with a 10mm pin. Will not fit E36 and E46 Cabriolet models Suspension Brand Rear Shock Absorber Shaft Diameter Original BMW 10mm AST 10mm Bilstein HD, Sport, PSS Coilovers 10mm FK Coilovers 10mm H&R Coilovers 10mm JRZ RS 12mm Koni Sport 10mm KW V1, 2, 3 10mm ST Coilovers 10mm Tein Coilovers 12mm The above list is meant as a guide only. If your shock absorber brand is not listed,measuring the OD of the shaft will determine whether PFR5-5630-10 orPFR5-5630-12 should be fitted.
30. PFR5-5630-12
Suits cars with aftermarket rear shock absorber with a 12mm pin. Will not fit E36 and E46 Cabriolet models. Suspension BrandRear Shock Absorber Shaft DiameterOriginal BMW10mmAST10mmBilstein HD, Sport, PSS Coilovers10mmFK Coilovers10mmH&R Coilovers10mmJRZ RS12mmKoni Sport10mmKW V1, 2, 310mmST Coilovers10mmTein Coilovers12mmThe above list is meant as a guide only. If your shock absorber brand is not listed,measuring the OD of the shaft will determine whether PFR5-5630-10 orPFR5-5630-12 should be fitted.
31. PFF5-4631
This part is 26mm long and can be 1 or 2 per depending on vehicle application.
35. EXH035
Fits all petrol models of E46 except M3. For M3 vehicles please use EXH034.
50. PFF5-4650
Tuneable engine mounts to suit your driving demands. This mount fits 6-cyl models only except the E46 Xi and Convertible models, and for the E9* it fits the M3 only. It will not fit the 4-cyl petrol engine for any models. We do not recommend fitting these mounts to diesel-engined vehicles due to excessive NVH. The Graph is showing Load against Movement, the peaks are at 5mm. PFF5-4650 is just under 200% stiffer at 5mm compression,with the 4 adjuster pins installed just under 300% over standard.
. PF5-4660
PF5-4660 is a polyurethane jack pad to fit into the plastic lifting points found on most modern BMW and related vehicles and is designed to help lift stability and location, whilst protecting the underside of your vehicle.
