1. PFF57-501-25 – Front Anti Roll Bar Bush 25mm
Fits 987.2 and 997.2 with the optional Porsche Active Suspension Management (PASM).
OEM Part Number: Bush = 996 343 792 17
OEM Part Number: Bar = 997 343 701 07 / 997 343 701 08 PASM
1. PFF57-501-24 – Front Anti Roll Bar Bush 24mm
Please check anti-roll bar diameter before ordering.
OEM Part Number: Bush = 99634379217 / 996 343 792 17
OEM Part Number: Bar = 996 343 701 20 / 996 343 701 24 / 997 343 701 07
OEM Part Number: Bar = 996 343 701 10 / 996 343 701 23
1. PFF57-501-23.5 – Front Anti Roll Bar Bush 23.5mm
Please check anti-roll bar diameter before ordering.
OEM Part Number: Bush = 996 343 792 12 / 996 343 792 17
OEM Part Number: Bar = 996 343 701 04 / 996 343 701 21 / 997 343 701 08
OEM Part Number: Bar = 996 343 701 10 / 996 343 701 23
2. PFF57-802 – Front Track Control Arm Outer Bush, Caster Adjustable
PFF57-802 uses our Black 95A material for ultimate performance and is supplied with a CNC machined sleeve and spanner for on-car adjustment of caster, with the sleeve being made from stainless steel 303 for increased corrosion and wear resistance.
OEM Part Number: 99634134108 / 996 341 341 08
OEM Part Number: 99734124400 / 997 341 244 00
2. PFF57-804 – Front Track Control Arm Outer Bush
OEM Part Number: 997.341.244.00
OEM Part Number: 996.341.341.08
3. PFF57-801 – Front Track Control Arm Inner Bush, Camber Adjustable
PFF57-801 allows the front camber angle to be adjusted on-car by +/- 0.75°. For non-adjustable use PFF57-503.
OEM Part Number: 996341053
OEM Part Number: 997341041
OEM Part Number: 997331053
5. PFF57-502 – Rear Track Control Arm Outer Bush
Fits the front of all 996 and Boxster 986 models. It fits the front of the 997 GT2, GT3 & GT3RS models only, all other models of 997 models use PFF57-802. – Fits the rear of 996, 997, 997 GT2, GT3 & GT3RS, Boxster 986, Boxster 987 and Cayman 987C.
OEM Part Number: 996341053 / 996341941 / 997341041
OEM Part Number: 997341042 / 997341041
OEM Part Number: 997331053
6. PFF57-503 – Rear Track Control Arm Inner Bush
No adjustment, concentric.
Fits the front of all 996 and Boxster 986 models. It fits the front of the 997 GT2, GT3 & GT3RS models only, all other models of 997 models use PFF57-801. – Fits the rear of 996, 997, 997 GT2, GT3 & GT3RS, Boxster 986, Boxster 987 and Cayman 987C.
OEM Part Number: 996341053
OEM Part Number: 997341041
OEM Part Number: 997331053
7. PFR57-507 – Rear Link Arm Inner Bush
OEM Part Number: 997 331 045 04 / 99733104504
8. PFR57-509 – Rear Upper Link Arm Outer Bush 2006 on
On some early 997 models (pre-2006) there is no support on the outside face of the link arm to hub bush. For these models use 4 x PFR57-508 for the link arm to hub bushes & 4 x PFR57-509 for the link arm to subframe bush. For hub carriers with support either side of the bush, use 8 x PFR57-509.
OEM Part Number: 99733104700 / 99733104701
OEM Part Number: 99633104702 / 99633104703
OEM Part Number: 99633104705 / 99633104706
8. PFR57-508 – Rear Upper Link Arm Outer Bush
On some early 997 models (pre-2006) there is no support on the outside face of the link arm to hub bush. For these models use 4 x PFR57-508 for the link arm to hub bushes & 4 x PFR57-509 for the link arm to subframe bush. For hub carriers with support either side of the bush, use 8 x PFR57-509. PFR57-508 fits 22mm width arms, for 19.5mm width arms please use PFR57-1508.
OEM Part Number: 99733104700 / 99733104701
OEM Part Number: 99633104702 / 99633104703
OEM Part Number: 99633104705 / 99633104706
8. PFR57-1508 – Rear Upper Link Arm Outer Bush
PFR57-1508 fits 19.5mm width arms, for 22mm width arms please use PFR57-508.
OEM Part Number: 99633104703
9. PFR57-509 – Rear Upper Link Arm Inner Bush
OEM Part Number: 99733104700 / 99733104701
OEM Part Number: 99633104702 / 99633104703
OEM Part Number: 99633104705 / 99633104706
9. PFR57-1509 – Rear Upper Link Arm Inner Bush
PFR57-1509 fits 19.5mm width arms, for 22mm width arms please use PFR57-509.
OEM Part Number: 99633104703
10. PFR57-510-22 – Rear Anti Roll Bar Bush 22mm
OEM Part Number: 996333792
10. PFR57-510-21 – Rear Anti Roll Bar Bush 21mm
OEM Part Number: 99633379226
OEM Part Number: 996 333 792 26
10. PFR57-510-20 – Rear Anti Roll Bar Bush 20mm
OEM Part Number: 99633379225
OEM Part Number: 996 333 792 25
10. PFR57-510-19 – Rear Anti Roll Bar Bush 19mm
OEM Part Number: 99633379228 / 996 333 792 28
OEM Part Number: 99933379224 / 996 333 792 24
10. PFR57-510-19.6 – Rear Anti Roll Bar Bush 19.6mm
OEM Part Number: 99633379228 / 996 333 792 28
OEM Part Number: 99933379224 / 996 333 792 24
10. PFR57-510-18.5 – Rear Anti Roll Bar Bush 18.5mm
OEM Part Number: 99633379228 / 996 333 792 28
OEM Part Number: 99933379224 / 996 333 792 24
30. PFR57-531 – Gearbox Front Mounting Bush Insert Kit
Fits 996 & 997 vehicles with the twin bush mounting bracket, as fitted to all 3.6 & 3.8 Tiptronic models, Turbo models Manual & Tiptronic, GT2 & GT3. For vehicles with a single bush in the end casing use PFR57-530. This will not fit the original 99637503303 transmission carrier.
OEM Part Number: 99737503303
30. PFR57-533 – Gearbox Front Mounting Bush Insert
Fits Gen 2 manual and PDK gearbox’s with a single bush in the end casing except for Turbo GT2 & GT3 models which use PFR57-531. For Gen 1 models please use PFR57-532.
OEM Part Number: 9A137505502
30. PFR57-532 – Gearbox Front Mounting Bush Insert
Fits manual gearbox with a single bush in the end casing except for Turbo GT2 & GT3 models which use PFR57-531. Does not fit Gen 2 997 models. For Gen 2 models please use PFR57-533.
OEM Part Number: 99737525500
40. PFR57-830 – Rear Top Mount Isolator Bush
PFR57-830 Rear Top Mount Isolator Bush is a direct replacement for the OE foam isolator, meaning that you no longer have to buy an expensive complete mount and can just replace the problematic part. It offers increased durability and performance while providing a cost-effective, fit-and-forget solution that’s a worthwhile upgrade as part of any rear suspension overhaul.
OEM Part Number: 997 333 061 00 / 997 333 061 01
OEM Part Number: 997 333 061 02 / 997 333 061 03
2F. PF57K-1002G – Track Control Arm & Bush Kit (Adjustable)
We can now supply a high-quality cast control arm pre-assembled with our signature polyurethane bushes for a fit-and-forget product explicitly designed for high performance and convenience of use, saving both time and money with the added peace of mind of our Lifetime Warranty. This arm features suspension geometry tuning, with a caster increase of up to 0.4° and camber adjustment of +/- 0.75°
OEM Part Number: 99134105304
OEM Part Number: 99734105304
OEM Part Number: 99134105321
2F. PF57K-1002 – Track Control Arm & Bush Kit
We can now supply a high-quality cast control arm pre-assembled with our signature polyurethane bushes for a fit-and-forget product explicitly designed for high performance and convenience of use, saving both time and money with the added peace of mind of our Lifetime Warranty.
OEM Part Number: 99134105304
OEM Part Number: 99734105304
OEM Part Number: 99134105321
5R. PF57K-1001G – Track Control Arm & Bush Kit (Adjustable)
We can now supply a high-quality cast control arm pre-assembled with our signature polyurethane bushes for a fit-and-forget product designed specifically for high performance and convenience of use, saving both time and money with the added peace of mind of our Lifetime Warranty. This arm features suspension geometry tuning, with a caster increase of up to 0.4° and camber adjustment of +/- 0.75°
OEM Part Number: 98133105301
OEM Part Number: 99733104180
OEM Part Number: 99634105318
5R. PF57K-1001 – Track Control Arm & Bush Kit
We can now supply a high-quality cast control arm pre-assembled with our signature polyurethane bushes for a fit-and-forget product explicitly designed for high performance and convenience of use, saving both time and money with the added peace of mind of our Lifetime Warranty.
OEM Part Number: 98133105301
OEM Part Number: 99733104180
OEM Part Number: 99634105318
PF57-560 – Jack Pad Adaptor
PF57-560 is a CNC aluminium jack pad that fits into the elongated lifting point on most modern Porsche vehicles, with a simple twist and lock action to locate securely. It is designed to help lift stability and location, whilst protecting the underside of your vehicle using high-strength 95A durometer polyurethane lifting pads, making this a must-have for Porsche owners and specialists alike.
PF57-561K – Bolt-On Jack Pad Adaptor Kit
PF57-561K Bolt-On Jack Pad Adaptor Kit is a kit of four anodised CNC-machined 6082-grade aluminium Jack Pads with a 95A durometer anti-slip base that fit into the four underbody lifting points on most modern Porsche vehicles including the classic 911.
They are designed to help lift stability and location whilst protecting the underside of your vehicle from damage.
To fit, locate the Jack Pad into the elongated factory lifting point, turn through 90 degrees and lock down securely using the plated Allen bolt with a standard 5mm Allen key. It’s as simple as that!
