1. PFF85-201 – Front Wishbone Front Bush 30mm
If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger 45mm bush PFF3-501. For an on-car camber adjustable version of this bush please use PFF85-201G.
OEM Part Number: 357407182
OEM Part Number: 191407182
2. PFF85-410PA – Front Wishbone Rear Bush, Pattern Arm
This bush is designed specifically to fit aftermarket arms with a hole depth of 21mm. For genuine OE arms that measure 23mm in depth, please use PFF85-410
OEM Part Number: 1J0407181
OEM Part Number: 1J0407151C
2. PFF85-414 – Front Wishbone Rear Bush (Track/Race)
This is a rose-jointed bush with PU inserts. It is recommended for Track/Race use.
OEM Part Number: 1J0407181
OEM Part Number: 8N0407181
2. PFF85-410 – Front Wishbone Rear Bush
Fits genuine OE pressed steel arms with 23mm hole depth. For aftermarket pressed steel arms with 21mm hole depth, use PFF85-410PA and for cast arms use PFF3-610.
OEM Part Number: 1J0407181
OEM Part Number: 1J0407151C
3. PFF85-411-23 – Front Anti Roll Bar Mount 23mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0 411 314 T
OEM Part Number: 1J0411314T
3. PFF85-411-21 – Front Anti Roll Bar Mount 21mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0 411 314 R
OEM Part Number: 1J0411314R
3. PFF85-411-21 – Front Anti Roll Bar Mount 21mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0 411 314 R
OEM Part Number: 1J0411314R
3. PFF85-411-19 – Front Anti Roll Bar Bush 19mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0411314
4. PFF85-413 – Front Anti Roll Bar Link Bush Kit
Fits plastic link rods only, for aluminium link rods use PFF85-412. Not for link rods with ball joints on the ends.
OEM Part Number: 1J0411315K
OEM Part Number: 1J0411315H
5. PFR3-510G – Rear Arm Inner Bush Camber Adjustable
These bushes offer on-car adjustment of the rear camber angles of up to 2 degrees. For a non-adjustable version of this bush please use PFR3-510.
OEM Part Number: 1J0505323N
OEM Part Number: 1J0505323L
5. PFR3-510 – Rear Arm Inner Bush
For an adjustable version of this bush please use PFR3-510G.
OEM Part Number: 1J0505323L
OEM Part Number: 1J0505323N
6. PFR3-511-16 – Rear Anti Roll Bar Mount 16mm
OEM Part Number: 1J0511327B
OEM Part Number: 8A0511327E
6. PFR3-511-15 – Rear Anti Roll Bar Mount 15mm
OEM Part Number: 8D0511327D
7. PFF85-416 – Steering Rack Mount Bush
OEM Part Number: 1J0422884A
8. PFF85-420 – Front Engine Mount Dog Bone (Petrol/Tuned Diesel)
Made in our Yellow 70A material, PFF85-420 is intended for petrol or tuned diesel vehicles. For significantly tuned petrol or diesel vehicles, or those being used on track, please use PFF85-420BLK. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mounting between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 1J0199851
OEM Part Number: 1J0199851AM
8. PFF85-420R – Front Engine Mount Dog Bone (Diesel)
Made in our softer Red 65A material, PFF85-420R is intended for standard diesel vehicles. For petrol or modified diesel vehicles, please use PFF85-420. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mounting between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 1J0199851
OEM Part Number: 1J0199851AM
9. PFR3-508G – Rear Trailing Arm Front Bush Toe Adjust
This part has been engineered to provide an additional 0.5 degrees positive toe adjustment, useful to correct excessive toe-in on heavily lowered cars. For a standard replacement part with no offset geometry, please use PFR3-508.
OEM Part Number: 1J0505171B
9. PFR3-508 – Rear Trailing Arm Front Bush
Also fits VW New Beetle Mk1 and Skoda Octavia MK1 4WD models. To adjust the vehicles rear toe angle, please use PFR3-508G.
OEM Part Number: 1J0505171B
10. PFF85-505 – Lower Engine Mount Small Bush
OEM Part Number: 1J0199851
OEM Part Number: 1K0199855
11. PFF85-431W – Front Strut Top Mount Bush Washer
PFF85-431W Front Strut Top Spacer (as normally supplied with PFF85-431 and now available separately) is a simple and cost-effective interim solution that fits and works with the OE Strut Top Cap to fill the gap and prevents binding up on the PU Spacer as the suspension turns.
Fitting couldn’t be easier either. Simply remove the existing Strut Top Cap from the car, separate the rubber ring from it, press the Cap into our Spacer and then refit it!
NB: fitting this part is only recommended if the installed Top Mount is in good condition and there is a gap of at least 12mm between the top cap and body. If the OE mount has collapsed, you will need to replace the entire mount with PFF85-430 or PFF85-431.
OEM Part Number: 1J0412331C
11. PFF85-431 – Front Strut Top Mount Bush -10mm
This part has been designed to reduce the ride height by 10mm when fitted as it allows the strut to sit higher into the body of the top mount. It is supplied with a new top cap spacer made using our 95A durometer material, meaning no more modifying of original parts. For standard ride height top mounts, please use PFF85-430.
OEM Part Number: 1J0412331C
11. PFF85-430 – Front Strut Top Mount Bush
OEM Part Number: 1J0412331C
24. PFF85-424 – Front Subframe Rear Bush
OEM Part Number: 1J0199429
OEM Part Number: 8N0199282C
OEM Part Number: 8N0199282D
25. PFR85-425 – Rear Diff Front Mounting Bush
This part fits into diff mounting bracket OE number 1J0599271D.
OEM Part Number: 1J0599381A
OEM Part Number: 1J0599271D
26. PFR85-426 – Rear Diff Rear Mounting Bush
This part fits into subframe OE number 1J0505235F.
OEM Part Number: 1J0599257B
OEM Part Number: 1J0505235F
27. PFR85-427 – Rear Subframe Mounting Bush
This part fits into subframe OE number 1J0505235F.
OEM Part Number: 1J0505145B
OEM Part Number: 1J0505235F
40. PFF85-440R – Upper Engine Mount Insert (Diesel)
PFF85-440R uses our softest Red 65A material, specifically designed to minimise NVH transmission. Recommended for unmodified Diesel models or for drivers who want a subtle improvement in driving feel, without compromising comfort. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the drivetrain and chassis. The harder the material used, the greater the NVH transmitted. Reducing engine/trans movement by way of upgraded inserts has the following benefits:
•tSharper throttle response
•tMore accurate gear changes
•tReduced wheel-hop
•tImproved Traction
•tProlonged mount life
OEM Part Number: 1JO 199 282 BF
40. PFF85-440 – Upper Engine Mount Insert
PFF85-440 uses our Yellow 70A durometer material, providing an excellent balance of strength and compliance for improved performance, whilst limiting NVH transmission into the cabin. This part is recommended for Petrol models and high-torque tuned Diesel models. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the drivetrain and chassis. The harder the material used, the greater the NVH transmitted. Reducing engine/trans movement by way of upgraded inserts has the following benefits:
•tSharper throttle response
•tMore accurate gear changes
•tReduced wheel-hop
•tImproved Traction
•tProlonged mount life
OEM Part Number: 1JO 199 282 BF
41. PFF85-441R – Upper Gearbox Mount Insert (Diesel)
PFF85-441R uses our softest Red 65A material, specifically designed to minimise NVH transmission. Recommended for unmodified Diesel models or for drivers who want a subtle improvement in driving feel, without compromising comfort. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the drivetrain and chassis. The harder the material used, the greater the NVH transmitted. Reducing engine/trans movement by way of upgraded inserts has the following benefits – Sharper throttle response – More accurate gear changes – Reduced wheel-hop – Improved Traction – Prolonged mount life. Does not fit mount 8N0199555C as fitted to S3 8L and TT Quattro 210/225PS with VIN 8L-Y-013 168>> onwards.
OEM Part Number: 1J019955 / 1J0 199 555
41. PFF85-441 – Upper Gearbox Mount Insert
PFF85-441 uses our Yellow 70A durometer material, providing an excellent balance of strength and compliance for improved performance, whilst limiting NVH transmission into the cabin. This part is recommended for Petrol models and high-torque tuned Diesel models. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the drivetrain and chassis. The harder the material used, the greater the NVH transmitted. Reducing engine/trans movement by way of upgraded inserts has the following benefits – Sharper throttle response – More accurate gear changes – Reduced wheel-hop – Improved Traction – Prolonged mount life. Does not fit mount 8N0199555C as fitted to S3 8L and TT Quattro 210/225PS with VIN 8L-Y-013 168>> onwards.
OEM Part Number: 1J019955 / 1J0 199 555
PF3-1663K – Jacking Point Insert Kit of 4
PFF3-1663 Jacking Point Insert is a 95A durometer polyurethane bung that presses up into the vacant hole in the chassis providing a fit and forget solution for safer lifting – Recommended for lifting across 4 lift points simultaneously to avoid damage. For those that have the OE lifting adaptors, PFF3-1662 Magnetic Jack Pad is a CNC-machined Jack Pad with a built-in magnet to suit OE lifting adaptors, 8N0803855 and 8N0804583, that many owners may already have fitted. Its magnetic head self-locates into the recess of the metal OE adaptor ensuring a safe and solid lift every time, again recommended for use in sets of 4 simultaneously.
OEM Part Number: 8N0804583
PF3-1663 – Jacking Point Insert
PFF3-1663 Jacking Point Insert is a 95A durometer polyurethane bung that presses up into the vacant hole in the chassis providing a fit and forget solution for safer lifting – Recommended for lifting across 4 lift points simultaneously to avoid damage. For those that have the OE lifting adaptors, PFF3-1662 Magnetic Jack Pad is a CNC-machined Jack Pad with a built-in magnet to suit OE lifting adaptors, 8N0803855 and 8N0804583, that many owners may already have fitted. Its magnetic head self-locates into the recess of the metal OE adaptor ensuring a safe and solid lift every time, again recommended for use in sets of 4 simultaneously.
OEM Part Number: 8N0804583
EXH023 – Exhaust Mount
OEM Part Number: 712770470 / 1756516020
OEM Part Number: 1H0253147B / 1H0253147C / 20650D0101
OEM Part Number: 255047 / 17565-28010
