1. PFF85-201G – Front Wishbone Front Bush 30mm Camber Adjustable
PFF85-201G gives +/- 0.5 degrees of camber adjustment. If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger (nonadjustable) 45mm bush PFF3-501.
OEM Part Number: 357407182
OEM Part Number: 191407182
1. PFF85-201 – Front Wishbone Front Bush 30mm
If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger 45mm bush PFF3-501. For an on-car camber adjustable version of this bush please use PFF85-201G.
OEM Part Number: 357407182
OEM Part Number: 191407182
2. PFF85-410PA – Front Wishbone Rear Bush, Pattern Arm
This bush is designed specifically to fit aftermarket arms with a hole depth of 21mm. For genuine OE arms that measure 23mm in depth, please use PFF85-410
OEM Part Number: 1J0407181
OEM Part Number: 1J0407151C
2. PFF85-414 – Front Wishbone Rear Bush (Track/Race)
This is a rose-jointed bush with PU inserts. It is recommended for Track/Race use.
OEM Part Number: 1J0407181
OEM Part Number: 8N0407181
2. PFF85-410 – Front Wishbone Rear Bush
Fits genuine OE pressed steel arms with 23mm hole depth. For aftermarket pressed steel arms with 21mm hole depth, use PFF85-410PA and for cast arms use PFF3-610.
OEM Part Number: 1J0407181
OEM Part Number: 1J0407151C
3. PFF85-411-23 – Front Anti Roll Bar Mount 23mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0 411 314 T
OEM Part Number: 1J0411314T
3. PFF85-411-21 – Front Anti Roll Bar Mount 21mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0411314T
3. PFF85-411-19 – Front Anti Roll Bar Bush 19mm
Please check anti roll bar diameter before ordering.
OEM Part Number: 1J0411314
4. PFF85-413 – Front Anti Roll Bar Link Bush Kit
Fits plastic link rods only, for aluminium link rods use PFF85-412. Not for link rods with ball joints on the ends.
OEM Part Number: 1J0411315K
OEM Part Number: 1J0411315H
4. PFF85-412 – Front Anti Roll Bar Link Bush Kit
Fits metal link rods only. For plastic link rods, use PFF85-413. These parts will not fit link rods with ball joint ends.
OEM Part Number: Bush = 1J0411327 / 1J0 411 327
OEM Part Number: Link = 1J0411315 / 1J0 411 315 G
5. PFR85-610 – Rear Beam Mounting Bush
Fits 2WD models only. PFR85-415 has been superseded with PFR85-610.
OEM Part Number: 1J0501541B / 1J0501541C / 1J0501541D
OEM Part Number: 6R0501541A / 6R0501541B / 6R0501541C
OEM Part Number: 6Q0501541E / 6Q0 501 541 E
7. PFF85-416 – Steering Rack Mount Bush
OEM Part Number: 1J0422884A
8. PFF85-420 – Front Engine Mount Dog Bone (Petrol/Tuned Diesel)
Made in our Yellow 70A material, PFF85-420 is intended for petrol or tuned diesel vehicles. For significantly tuned petrol or diesel vehicles, or those being used on track, please use PFF85-420BLK. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mounting between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 1J0199851
OEM Part Number: 1J0199851AM
8. PFF85-420R – Front Engine Mount Dog Bone (Diesel)
Made in our softer Red 65A material, PFF85-420R is intended for standard diesel vehicles. For petrol or modified diesel vehicles, please use PFF85-420. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mounting between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 1J0199851
OEM Part Number: 1J0199851AM
9. PFF85-505 – Lower Engine Mount Small Bush
OEM Part Number: 1J0199851
OEM Part Number: 1K0199855
11. PFF85-431W – Front Strut Top Mount Bush Washer
PFF85-431W Front Strut Top Spacer (as normally supplied with PFF85-431 and now available separately) is a simple and cost-effective interim solution that fits and works with the OE Strut Top Cap to fill the gap and prevents binding up on the PU Spacer as the suspension turns.
Fitting couldn’t be easier either. Simply remove the existing Strut Top Cap from the car, separate the rubber ring from it, press the Cap into our Spacer and then refit it!
NB: fitting this part is only recommended if the installed Top Mount is in good condition and there is a gap of at least 12mm between the top cap and body. If the OE mount has collapsed, you will need to replace the entire mount with PFF85-430 or PFF85-431.
OEM Part Number: 1J0412331C
11. PFF85-431 – Front Strut Top Mount Bush -10mm
This part has been designed to reduce the ride height by 10mm when fitted as it allows the strut to sit higher into the body of the top mount. It is supplied with a new top cap spacer made using our 95A durometer material, meaning no more modifying of original parts. For standard ride height top mounts, please use PFF85-430.
OEM Part Number: 1J0412331C
11. PFF85-430 – Front Strut Top Mount Bush
OEM Part Number: 1J0412331C
24. PFF85-424 – Front Subframe Rear Bush
OEM Part Number: 1J0199429
OEM Part Number: 8N0199282C
OEM Part Number: 8N0199282D
