1. PFF85-201G – Front Wishbone Front Bush 30mm Camber Adjustable
PFF85-201G gives +/- 0.5 degrees of camber adjustment. If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger (nonadjustable) 45mm bush PFF3-501.
OEM Part Number: 357407182
OEM Part Number: 191407182
1. PFF85-201 – Front Wishbone Front Bush 30mm
If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger 45mm bush PFF3-501. For an on-car camber adjustable version of this bush please use PFF85-201G.
OEM Part Number: 357407182
OEM Part Number: 191407182
2. PFF85-1202 – Front Arm Rear Bush
For the Skodia Fabia 5J, this bush only fits models with these chassis numbers: F5J 8A502 657 Onward, F5J 8B503 032 Onward, F5J 8K450 961 Onward, F5J 83172 974 Onward.
OEM Part Number: 1J0 407 181 / 1J0 407 181 B = Bush
OEM Part Number: 6R0 407 151 / 6R0 407 152 = Arm
3. PFF85-603-20 – Front Anti Roll Bar Bush 20mm
OEM Part Number: Bar = 6Q0411305AN / 6R0411305B
OEM Part Number: Bush = 6Q0411314R
4. PFF85-431 – Front Strut Top Mount Bush -10mm
This part has been designed to reduce the ride height by 10mm when fitted as it allows the strut to sit higher into the body of the top mount. It is supplied with a new top cap spacer made using our 95A durometer material, meaning no more modifying of original parts. For standard ride height top mounts, please use PFF85-430.
OEM Part Number: 1J0412331C
4. PFF85-430 – Front Strut Top Mount Bush
OEM Part Number: 1J0412331C
8. PFR85-508 – Rear Tie Bar to Chassis Front Bush
OEM Part Number: Bush = 1K0505541D
OEM Part Number: Bush = 5C0501541A
9. PFR85-817 – Rear Lower Arm Outer Bush
OEM Part Number: 1K0505553A / 1K0 505 553 A
10. PFR85-818 – Rear Lower Arm Inner Bush
OEM Part Number: 1K0505311AB / 1K0 505 311 AB
11. PFR85-511 – Rear Lower Track Rod Outer Bush
OEM Part Number: Arm = 1K0501529F / 1K0 501 529 F
OEM Part Number: Arm = 1K0501529J / 1K0 501 529 J
OEM Part Number: Arm = 1K0501529C / 1K0 501 529 C
12. PFR85-512 – Rear Lower Track Rod Inner Bush
OEM Part Number: Arm = 1K0501529F / 1K0 501 529 F
OEM Part Number: Arm = 1K0501529J / 1K0 501 529 J
OEM Part Number: Arm = 1K0501529C / 1K0 501 529 C
13. PFR85-513G – Rear Upper Wishbone Outer Bush Camber Adjustable
PFR85-513G Rear Upper Wishbone Outer Bush is a camber adjustable version of our existing PFR85-513 Rear Wishbone Outer Bush for a variety of VAG models. Made in our Black 95A durometer material and supplied with a CNC-machined offset-bore sleeve and adjusting spanner, it offers a range of up to +/- 1.0° of on-car camber adjustment at the rear suspension knuckle.
OEM Part Number: Arm = 5Q0505323D / 5Q0 505 323 D
OEM Part Number: Arm = 5Q0505351B / 5Q0 505 351 B
OEM Part Number: Arm = 1K0505323N / 1K0 505 323 N
13. PFR85-513 – Rear Upper Wishbone Outer Bush
OEM Part Number: Arm = 5Q0505323D / 5Q0 505 323 D
OEM Part Number: Arm = 1K0505323N / 1K0 505 323 N
14. PFR85-514 – Rear Upper Wishbone Inner Bush
OEM Part Number: Arm = 5Q0505323D / 5Q0 505 323 D
OEM Part Number: Arm = 1K0505323N / 1K0 505 323 N
15. PFR85-515-21.7 – Rear Anti Roll Bar Bush 21.7mm
Please check anti roll bar diameter before ordering
OEM Part Number: 1K0511327AS
20. PFF85-620P – Lower Engine Mount Large Bush (Tuned/Track)
PFF85-620P uses our Purple 80A durometer material and is suitable for significantly tuned cars or those used on track. Fitting this engine mount bush to 1.4 TDI 3 cylinders is not advisable. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 6Q0199851AA / 6Q0199851AC
OEM Part Number: 6Q0199851AP / 6Q0199851AT
OEM Part Number: 8Z0199851H
20. PFF85-620 – Lower Engine Mount Large Bush (Std Petrol)
PFF85-620 is made using our Yellow 70A durometer material and is suitable for standard petrol models or mildly tuned diesel models. For track/tuned models use PFF85-620P. Fitting this engine mount bush to 1.4 TDI 3 cylinders is not advisable. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted.
OEM Part Number: 6Q0199851AA / 6Q0199851AC
OEM Part Number: 6Q0199851AP / 6Q0199851AT
OEM Part Number: 8Z0199851H
24. PFR85-523 – Rear Diff Front Mounting Bush
This bush fits models only where the bush location in the diff casing measures 30mm tall as found on AWD 2004-2015 PQ35 platform vehicles. If in doubt, measure the height of the front casing mount before ordering. If the mount is 35mm in height and the OEM part number on your vehicle is 1K0 599 437, please use PFR85-524.
OEM Part Number: 1K0599431
25. PFR85-525 – Rear Diff Rear Mounting Bush
This bush fits 4 wheel drive models only.
OEM Part Number: 1K0599437 / 1K0 599 437
OEM Part Number: 1K0599438 / 1K0 599 438
27. PFR85-827 – Rear Subframe Front Mounting Bush
This bush uses our Purple 80A durometer material with bonded supporting washers for strengthening and a bespoke end face design to reduce noise transmission to the cabin, whilst maintaining durability and subframe location.
OEM Part Number: 5Q0 505 145 F
OEM Part Number: 5Q0 505 145 D
OEM Part Number: 5Q0 505 145 J
28. PFR85-828 – Rear Subframe Rear Mounting Bush
This bush uses our Purple 80A durometer material with bonded supporting washers for strengthening and a bespoke end face design to reduce noise transmission to the cabin, whilst maintaining durability and subframe location.
OEM Part Number: 5Q0 505 145 E
OEM Part Number: 5Q0 505 145 K
OEM Part Number: 5Q0 505 145 H
